Tutorials

Bedrich Rios at NETTUTS.com has put together a tutorial for creating keypress navigation using the jQuery JavaScript library. A keypress navigation, if implemented well, can increase usability of your web applications and sites. Basically, you create a way for users to navigate through your site [or part of it] without the use of their mouse. This has long been possible/common with rich desktop applications, but usually isn't implemented in many of today's web applications.

Bedrich's 8 step tutorial will have you creating keypress navigations in no time. Check out the demo if you want to get a taste. For the 8 course meal, visit How to Create A Keypress Navigation Using jQuery

If you want to get XML data from a different domain you will need to use a server side proxy. While you could use JSON to get around this there are times when a JSON feed may not be available and a proxy must be used.

In the past I have written posts about creating such a proxy, however all of the example code was is PHP. Well, if you are a .NET developer then you are in luck, because the CodeProject has posted a tutorial on creating a Server Side Proxy in .NET.

Below is an excerpt from the post.

A Basic Proxy Such a content proxy is also available in my open source Ajax Web Portal Dropthings.com. You can see from its code from CodePlex how such a proxy is implemented. The following is a very simple synchronous, non-streaming, blocking Proxy:

[WebMethod]
[ScriptMethod(UseHttpGet=true)]

public string GetString(string url)
{
        using (WebClient client = new WebClient())
        {
            string response = client.DownloadString(url);
            return response;
        }
    }
}


Although it shows the general principle, but it's no where close to a real proxy because:

• It's a synchronous proxy and thus not scalable. Every call to this
  web method causes the ASP.NET thread to wait until the call to the
  external URL completes.
• It's non streaming. It first downloads the entire
  content on the server, storing it in a string and then uploading that
  entire content to the browser. If you pass MSDN feed URL,
  it will download that gigantic 220 KB RSS XML on the server and store
  it on a 220 KB long string (actually double the size as .NET strings
  are all Unicode string) and then write 220 KB to ASP.NET Response
  buffer, consuming another 220 KB UTF8 byte array in memory. Then that
  220 KB will be passed to IIS in chunks so that it can transmit it to
  the browser.
• It does not produce proper response header to cache the response on the server. Nor does it deliver important headers like Content-Type from the source.
• If external URL is providing gzipped content, it decompresses
  the content into a string representation and thus wastes server memory.
• It does not cache the content on the server. So, repeated
  call to the same external URL within the same second or minute will
  download content from the external URL and thus waste bandwidth on your
  server.

So, we need an asynchronous streaming proxy that transmits
the content to the browser while it downloads from the external domain
server. So, it will download bytes from external URL in small chunks
and immediately transmit that to the browser. As a result, browser will
see a continuous transmission of bytes right after calling the web
service. There will be no delay while the content is fully downloaded
on the server.

You can read the full tutorial here.

This post not only shows you haw to make a basic server side proxy, but also shows you how to make it streaming. If you are a .NET developer looking to make a server side proxy, I recommend this post.

John Resig has written a good overview of Processing. Processing is a data visualization language written in Java that has been compared favorably to Flash. I first saw the language a couple of years ago and was very interested in it, but haven't seen much on it until this.

Below is an excerpt from the post.

Processing is a data visualization programming language.

It has three components:

• The Processing language
• The Processing drawing API
• The implementation (in Java - can optionally pass the drawing API through to OpenGL).

The Processing Language and API

• Strictly typed
• Has classes, inheritance
• Includes a bunch of globally-accessible functions (the drawing API - very flat and PHP-like).

Basic Program Structure

Two core methods: setup() and draw()

• Very OpenGL-like
• draw() is called continually at a specific framerate (if none is specified then it goes as fast as possible)

Simple example: Drawing a continuous line with the mouse.

void setup() {
  size(200, 200);
  background(102);

}

void draw() {
  stroke(255);
  if(mousePressed) {

    line(mouseX, mouseY, pmouseX, pmouseY);
  }
}

You can read the full post here.

Processing is a very interesting language and I could see it being very useful for applications that need a better way to represent information than is available in browser rendering. If you have never seen Processing, then you should look at some of the examples in John's post.

If you're interested in learning more about Ajax development, distributed systems, web security, or C++/Java/Python and you haven't checked out Google Code University, you're missing out on a valuable educational resource on these topics and more.

Here's a sample video from the site:
Web 2.0 - AJAX - Creating a Rich User Experience

Description: Incorporated AJAX is enabling the creation of applications with better functionality, usability, and an overall better user experience. This panel will discuss how desktop-like applications can be delivered via the browser with Ajax, the efficiency of developing such applications, and the importance of the GUI. They will also share their thoughts on highly successful applications and the shortcomings of using Ajax.

Also on the site, you'll find a series of Web Programming lecture slides provided by the University of Washington.

• Lecture 1 - The Internet and World Wide Web
• Lecture 2 - Hypertext Markup Language (HTML)
• Lecture 3 - Cascading Style Sheets (CSS)
• Lecture 4 - Page Layout with CSS
• Lecture 5 - JavaScript
• Lecture 6 - HTML User Interface Controls
• Lecture 7 - JavaScript Events
• Lecture 8 - Document Object Model (DOM)
• Lecture 9 - Asynchronous Javascript + XML (Ajax)
• Lecture 10 - Extensible Markup Language (XML)
• Lecture 11 - Debugging
• Lecture 12 - Multimedia
• Lecture 13 - Google Ajax Search API
• Lecture 14 - HTML Forms
• Lecture 15 - PHP
• Lecture 16 - HTML Tables
• Lecture 17 - SQL
• Lecture 18 - Cookies and Sessions
• Lecture 19 - Taking a Website Live
• Lecture 20 - Web Design and Usability
• Lecture 21 - What's Next?

For these and other great resources, visit the Google Code University

Have you ever designed a page for a web application and wanted to make a nice button for the application? You probably opened your photo editor and started working on the button. But, what if your design resizes itself based on the users browser size? You will probably want the button to resize as well. Well, over at CSS Globe they have written a script to do just that using CSS.

Below is an excerpt from the article explaining the concept.

Concept

This concept is probably familiar to you from various navigation tab styling techniques. We have one long background image:

This one is 550px wide. I believe that is more than sufficient for buttons :)

So, we apply this image as a background image of a top element (in this case SPAN), place it to top left and add some left padding. Nested element (in this case EM) have the same background image but placed to top right and with right padding. As the content text grows so will the button.

Height of the button is fixed in my example but you can use similar technique and some more markup and place the same background image to all 4 corners.

To make sure that the text is vertically centered I use line-height property.

The HTML that is required for applying the CSS to would be the below.

<button><span><em>Button text</em></span></button>

The below is the CSS that is used.

button{
	border:none;
	background:none;
	padding:0;
	margin:0;
	width:auto;
	overflow:visible;
	text-align:center;
	white-space:nowrap;
	height:40px;
	line-height:38px;
	}
button span, button em{
	display:block;
	height:40px;
	line-height:38px;
	margin:0;
	color:#954b05;
	}
button span{
	padding-left:20px;
	background:url(bg_button.gif) no-repeat 0 0;
	}
button em{
	font-style:normal;
	padding-right:20px;
	background:url(bg_button.gif) no-repeat 100% 0;
	}

You can read the full post here.

You can see the demo here and you can download the source code and image here.

This code could be very useful and I will probably use it in my next application. If you have used a technique like this in an application that you've made I'd love to hear about it, you can leave it in the comments.

I came across this beginner CSS tutorial I'd like to share with those of you that haven't had much experience with CSS.

Topic's include:
* What Is CSS?
* CSS Selectors
* CSS Units
* CSS Inline
* CSS Internal
* CSS External
* CSS Colors
* CSS Fonts
* CSS Text

Here's an excerpt from the tutorial on the advantages of CSS:

* Quick layout changes: Because all your CSS styles are in one or more .css files which are re-used for all pages it's easy to change the look of your website. For instance to add a 5 pixel wide red border to all your images you can simply write img {border:5px solid red}. This saves a lot of time as opposed to changing every single image tag in all your pages.
* Smaller file size: Separating content from presentation helps keep HTML file sizes down and improves page loading times. Once CSS files have been loaded for the first time they will be cached by the browser and loaded instantly for all following pages that use the same style sheets.
* Consistency: With CSS it's easy to keep a consistent look throughout your website.
* Cascading: Multiple style definitions will cascade into one, i.e. the last written one will overwrite all previous ones. This is very useful if you need to work with an existing style sheet and want to make some changes without altering the original code.
* Accessibility: Having content separated from presentation is a great help to people with viewing disabilities who often benefit from well structured HTML to understand the page.
* Design without tables: Before CSS lots of web designers mis-used tables to position elements on their page which is a bad thing for accessibility and also makes the code unnecessarily big and complicated. With CSS you can position any element exactly where you want without using tables.

Click here to visit the tutorial

jQuery is a great library for animation and Ajax calls. As with any JavaScript library there are different objects and name spaces to learn. Well, over at Web Designer Wall they have put together a good tutorial about using jQuery. The tutorial is written from a designers stand point, but even an experienced hard-core web programmer can find this tutorial useful.

Below is an excerpt from the post:

How jQuery works?

First you need to download a copy of jQuery and insert it in your html page (preferably within the <head> tag). Then you need to write functions to tell jQuery what to do. The diagram below explains the detail how jQuery work:

How to get the element?

Writing jQuery function is relatively easy (thanks to the wonderful documentation). The key point you have to learn is how to get the exact element that you want to apply the effects.

• $("#header") = get the element with id="header"
• $("h3") = get all <h3> element
• $("div#content .photo") = get all element with class="photo" nested in the <div id="content">
• $("ul li") = get all <li> element nested in all <ul>
• $("ul li:first") = get only the first <li> element of the <ul>

1. Simple slide panel

Let’s start by doing a simple slide panel. You’ve probably seen a lot of this, where you click on a link and a panel slide up/down. (view demo)

When an elment with class="btn-slide" is clicked, it will slideToggle (up/down) the <div id="panel"> element and then toggle a CSS class="active" to the <a class="btn-slide"> element. The .active class will toggle the background position of the arrow image (by CSS).

$(document).ready(function(){

	$(".btn-slide").click(function(){
	  $("#panel").slideToggle("slow");
	  $(this).toggleClass("active");
	});

});

2. Simple disappearing effect

This sample will show you how to make something disappear when an image button is clicked. (view demo)

When the <img class="delete"> is clicked, it will find its parent element <div class="pane"> and animate its opacity=hide with slow speed.

$(document).ready(function(){

	$(".pane .delete").click(function(){
	  $(this).parents(".pane").animate({ opacity: "hide" }, "slow");
	});

});

3 Chain-able transition effects

Now let’s see the power of jQuery’s chainability. With just several lines of code, I can make the box fly around with scaling and fading transition. (view demo)

Line 1: when the <a class="run"> is clicked

Line 2: animate the <div id="box"> opacity=0.1, left property until it reaches 400px, with speed 1200 (milliseconds)
Line 3: then opacity=0.4, top=160px, height=20, width=20, with speed "slow"
Line 4: then opacity=1, left=0, height=100, width=100, with speed "slow"

Line 5: then opacity=1, left=0, height=100, width=100, with speed "slow"
Line 6: then top=0, with speed "fast"
Line 7: then slideUp (default speed = "normal")
Line 8: then slideDown, with speed "slow"

Line 9: return false will prevent the browser jump to the link anchor

$(document).ready(function(){

	$(".run").click(function(){

	  $("#box").animate({opacity: "0.1", left: "+=400"}, 1200)
	  .animate({opacity: "0.4", top: "+=160", height: "20", width: "20"}, "slow")
	  .animate({opacity: "1", left: "0", height: "100", width: "100"}, "slow")
	  .animate({top: "0"}, "fast")
	  .slideUp()
	  .slideDown("slow")
	  return false;

	});

});

4a. Accordion #1

Here is a sample of accordion. (view demo)

The first line will add a CSS class "active" to the first <H3> element within the <div class="accordion"> (the "active" class will shift the background position of the arrow icon). The second line will hide all the <p> element that is not the first within the <div class="accordion">.

When the <h3> element is clicked, it will slideToggle the next <p> and slideUp all its siblings, then toggle the class="active".

$(document).ready(function(){

	$(".accordion h3:first").addClass("active");
	$(".accordion p:not(:first)").hide();

	$(".accordion h3").click(function(){

	  $(this).next("p").slideToggle("slow")
	  .siblings("p:visible").slideUp("slow");
	  $(this).toggleClass("active");
	  $(this).siblings("h3").removeClass("active");

	});

});

4b. Accordion #2

This example is very similar to accordion#1, but it will let you specify which panel to open as default. (view demo)

In the CSS stylesheet, set .accordion p to display:none. Now suppose you want to open the third panel as default. You can write as $(".accordion2 p").eq(2).show(); (eq = equal). Note that the indexing starts at zero.

$(document).ready(function(){

	$(".accordion2 h3").eq(2).addClass("active");
	$(".accordion2 p").eq(2).show();

	$(".accordion2 h3").click(function(){
	  $(this).next("p").slideToggle("slow")
	  .siblings("p:visible").slideUp("slow");
	  $(this).toggleClass("active");
	  $(this).siblings("h3").removeClass("active");
	});

});

You can read the full post here.
You can also view the demo here or download the demo code here.

jQuery is one library that I really recommend using. The library is very well written and is pretty easy to learn fairly quickly. If you haven't used the library before this is a good tutorial to start with.

For those of us who have lamented the sad state of debugging in Microsoft's Internet Explorer (and no, the Microsoft Script Debugger doesn't count), some relief is here. Complementing the IE Developer Toolbar, the Microsoft Visual Studio 2008 Web Developer Express Edition (and previously the 2005 Express Edition) gives you full JavaScript debugging ability from within the VS development environment without needing the paid version. The only drawback vis-a-vis the professional edition is that the page must be launched from with the IDE (rather than from IE itself). A small price to pay for desperately needed functionality.

Here's some quick steps to get you started:

1. Download the Web Developer Express Edition for free (though registration is required to activate it).
2. Create an empty web site, File-->Web Site...-->Empty Web Site.
3. Deposit the files you wish to debug in the web site folder, and open the file you wish to debug. Place desired break points. (Or you can skip this step if you just intend to just navigate to a URL later.)
4. Click the "Start Debugging" button. If you skipped step #3 and wish to navigate to a URL, then you may want to put at least one debugger statement in your JavaScript code so that the debugger will stop at this statement. Breakpoints can then be set within the IDE elsewhere.
5. Controls are in the Debug menu. F10 will step over, F11 will step into, etc.
6. All the expected debugging views are there: Call Stack, Locals (variables), Watch, and so forth.

Not quite as convenient as having Firebug directly in your browser, but a first-class JavaScript debugger (as JavaScript debuggers go...) nonetheless.

Over at the Web Cash blog they have posted two tutorials on Game development in JavaScript, Ajax and PHP. The first tutorial explains the concept and describes how to make a game board.

Below is an excerpt from the first tutorial.

Game Development with JS, AJAX, and PHP

How can we use JS and PHP - connected through AJAX - to develop an online game?

Javascript’s main use for us is to create an interface for the game. Through Javascript we can capture user input - i.e. mouse clicks and text. We can also alter the game’s output - changing the HTML of the page, adding images, and moving things around. Javascript will provide a lot of the front end work.

PHP, on the other hand, is a more robust language for dealing with the logic of the game. PHP could be useful for developing an AI and evaluating winning conditions. It also offers a great way to store information for later use through flat files or database integration.

If we’re going to use both Javascript and PHP, we’ll need to use AJAX. This is the glue that holds the whole thing together. It will send input from the main Javascript to the PHP processing scripts. The PHP script will then send info back to the Javascript and it will alter the page’s layout accordingly.

Read the full first tutorial here.

The second tutorial goes into more detail as to how you would start creating a simple game. By the end of the tutorial you have a complete simple tic-tac-toe game (the game needs more logic added to be finished, but the concept is there).

Below is an excerpt from the second tutorial.

Creating Graphics

I created two images in Inkscape to use for this board. Each is a 50×50 png file - with a gray background and a black border. The actual token (the circle or cross) is red and laid on top of the gray background.

I’m no great artist, but these should work for a functional demo. We can worry about making nice circle and cross tokens later. I think getting the game working is more important than making it pretty from the get-go.

Turning Our .js Script into a Class

In making this a functional board, I also converted the script into an actual class. The script may end up being somewhat large and unwieldy - and an object oriented approach may help us keep it tidy and clean. Or it may add a lot of overhead… but I like objects.

In our HTML file, we’ll create the object like this.

<script type="text/javascript">
var tictactoe = new game();
</script>

In the attached .js file, we actually define the game object. Here’s part of the object definition.

function game() {
  //  Array to hold the bgImgs
  this.bgImgs = new Array();
    this.bgImgs[0] = 'tttcircle.png';
    this.bgImgs[1] = 'tttcross.png';


  //  Player information
  this.currentPlayer = 0;
  this.players = new Array();
    this.players[0] = "Player One";
    this.players[1] = "Player Two";


   return true;

This class constructor does some of the initialization for us.

First, it creates an array with background images. At the moment we’re only using two images. However, this technique would be useful if you had a more complex map - with 10-15 images you could lay over a div.

Second, we create some player information variables. The ‘currentPlayer’ property is going to track whether the ‘cross’ or ‘circle’ player is currently taking a turn. The ‘players’ array will just hold the names of those players for now.

The Background Image Changing Function

One of the major methods of this class will be changeBackground(). Just like in the previous example, this method will change the background style of a given div tag. This way we can change it from an open square to a circle or cross token.

  this.changeBackground = function (boxId) {
    var box = document.getElementById('box-' + boxId);
    box.style.background = 'transparent url(' +
      this.bgImgs[this.currentPlayer] + ') top left no-repeat';


    box.removeAttribute('onClick');

    this.changePlayer();
  }

This should be pretty straightforward. We’re storing the ‘div’ element in the ‘box’ variable. We’re then setting the ‘background’ style as we would in a css style. Remember that we stored the background images in an array (this.bgImgs) and this.currentPlayer corresponds to a key in the this.bgImgs array (either 0 or 1).

The ‘box.removeAttribute()’ method is removing ‘onClick’ from that div. We can’t use a square a second time, so we might as well eliminate the onClick handler altogether.

Finally, this.changePlayer() is calling a new method. This is going to help us switch from Player One’s turn to Player Two’s turn.

One Turn to Another - this.changePlayer()

The last method we need to declare for this class at the moment is changePlayer.

This will toggle the active player - which in turn affects whether a circle or cross is placed on the board. For some added effect, we’ll also create a new html element to display a message that says who’s turn it is.

  this.changePlayer = function () {
    //  Switch the active player

    if (this.currentPlayer == 0) {
      this.currentPlayer = 1;
    } else {

      this.currentPlayer = 0;
    }

    //  Get a reference to our 'message' element and create the message
    var box = document.getElementById('message');
    var msg = "It is " + this.players[this.currentPlayer] + "'s turn.";
    var txt = document.createTextNode(msg);


    //  Erase any existing text
    while (box.hasChildNodes()) {
      box.removeChild(box.lastChild);
    }


    //  Add the text node (our message) to our element
    box.appendChild(txt);
  }

Again, this is pretty straightforward. The DOM functions are amazingly simple - once you see how they work.

‘box’ is a reference to our element (id = message). The msg variable is a temp variable I created to hold the string. The ‘createTextNode’ method creates a new block of text (with our msg) that we can then insert into an HTML element.

The while() loop is simply there to erase any old text. As long as our ‘box’ element has any child nodes inside of it (text or other HTML tags), the loop will execute and delete one of those child nodes each time. This way we have a clean slate on which to write down who’s turn it is.

Read the full second tutorial here.

Although the tutorial only shows a simplistic tic-tac-toe game you could use the concepts as a starting point to build your own web games. As always if you have made any cool games we would love to hear about them either in the comments or you can write a blog post about it using your free Ajaxonomy account.

Have you ever been designing a web page or web application that displayed quite a few thumbnails? Perhaps at times it would be nice to have larger thumbnails, but
